Concealed Industrial Power Outlet

HFN-4132/HFN-4132-4
Concealed industrial power outlet combination of rugged design, high-performance capabilities, user-friendliness, and safety features makes it the ideal solution to ensure uninterrupted power supply and operational efficiency in challenging outdoor environments.

Send Inquiry

Product Introduction

Zhejiang Hefeng Electric Co., Ltd. is one of the most reliable manufacturers and suppliers of concealed industrial power outlet in China. With abundant experience, we warmly welcome you to buy high-grade concealed industrial power outlet for sale here from our factory. All OEM products are with high quality and low price.

Product Details

Concealed industrial power outlet combination of rugged design, high-performance capabilities, user-friendliness, and safety features makes it the ideal solution to ensure uninterrupted power supply and operational efficiency in challenging outdoor environments.

Application of concealed industrial power outlet

The concealed industrial power outlet are a new generation of power connection devices. They have the characteristics of international use, safety and reliability. Suitable for multiple purposes. It is gradually used in steel smelting, petrochemical, electric power, electronics, construction sites, airports, mines, mining farms, water supply and drainage treatment plants, ports, docks, shopping malls, hotels, and gardens. The matching and maintenance parts of the concealed industrial power outlet are the ideal power connection device of the new generation. Various industrial and mining enterprises will be more widely used in construction.

Structure

Screw terminal block

With high temperature contact carrier

Integrated housing structure

With cable gland and seal

With strain relief to prevent cable breakage

Technical Parameter

Product name	panle mount socket
Current	16A/32A
Earth contact position	Standard: 4h,6h 2h,3h,7h,9h,10h,*special earth contact position customize available
Ltem code	16A	3 pin (2P+E)	HFN-4132/HFN-4132-4
		4 pin (3P+E)	HFN-4142/HFN-4142-4
		5 pin (3P+N+E)	HFN-4152/HFN-4152-4
	32A	3 pin (2P+E)	HFN-4232/HFN-4232-4
		4 pin (3P+E)	HFN-4242/HFN-4242-4
		5 pin (3P+N+E)	HFN-4252/HFN-4252-4
Protection degree	IP67
Voltage	110-130V~,220-250V~,380-415~,415V~
Standard	EN/ IEC 60309-1/2
Certification	CE, ROHS, TUV, CB

Dimensions

product-1200-568

Current	16A			32A
number of poles	3 pin (2P+E)	4 pin (3P+E)	5 pin (3P+N+E)	3 pin (2P+E)	4 pin (3P+E)	5 pin (3P+N+E)
a	75	75	75	75	75	75
b	75	75	75	75	75	75
C	61	61	61	61	61	61
d	61	61	61	61	61	61
e	18	18	18	22	22	22
f	63	63	63	75	75	67
g	40	44	52	49	49	56
h	40	44	52	49	49	56
i	5.5	5.5	5.5	5.5	5.5	5.5
Cable cross-section area(m m²)	1~2.5			2.5~6

※ Customization is available for special voltages, grounding locations, colors, etc.

FAQ

Q: In what types of applications is the Industrial Plug 32A typically used?

A: It is commonly used in applications that require substantial electrical power, such as large machinery, equipment, and systems in manufacturing, construction, and heavy-duty industrial environments. Its durability and high current rating make it suitable for these demanding applications.

Q: Can I get a free sample?

A: We are supply only one piece sample of free,and do freight collect.

Q: Are your products any certified?

A: Yes, all our products already got CE, CQC,ROHS cerfitcations.
