Camlock Connectors
400A Camlock connector
Camlock connectors have become an essential solution for high-current electrical connections across many industries. Their combination of fast installation, high power capacity, reliable performance, and flexible design makes them ideal for temporary power distribution, industrial applications, event production, generator systems, and renewable energy projects.
Product Details
This product consists of an insulated plastic shell, an inner support frame, and copper core pins, and is compatible with both male and female sockets. The shell is available in five colors to suit different power phases in various regions. The plug shell features a non-slip plastic handle for easy use. The tail end has pre-cut cable markings for different cable sizes. The design uses a non-conductive locking screw that passes through the copper pin, securely fixing it in the insulating sleeve. Installation and disassembly are tool-free and easy, and it is compatible with other brands of cam-type power connectors. It is a professional connector suitable for temporary power supplies in indoor and outdoor stage performances, film shooting, exhibitions, and generators.
Technical Parameter
|
Shell material |
TPE (Santoprene) |
|
Fixed Tip material |
Nylon |
|
Pins material |
Brass |
|
Waterproof Degree |
IP44 |
|
Temperature Range |
-40℃ ~ +90℃ |
|
Rated Current |
150A,200A,400A |
|
Rated Voltage |
600V AC/250V DC max |
Product Applications
Stage equipment undergoes frequent plug‑and‑unplug, rough transportation and complex indoor‑outdoor working conditions. Our 400A camlock connector adopts high‑conductivity copper contacts and flame‑retardant impact‑resistant shell. It resists abrasion, temperature change and occasional splashing, supporting hundreds of mating cycles for repeated rental use, which fits the high‑frequency turnover feature of stage rental business.
Color‑coded housing design is another vital advantage for stage working scenarios. Different colors mark phase, neutral and earth respectively, helping electricians identify circuits quickly even in dim back‑of‑stage environment, greatly lowering wiring mis‑connection risks during fast setup and teardown of touring events. Whether connecting mobile generators to main distribution boxes, linking feeder cables between power distro racks, or supplying power for broadcast vehicles, camlock connectors deliver stable high‑current transmission continuously.
At Zhejiang Hefeng Electric Co.,Ltd, every camlock connector passes strict high‑current, insulation and durability tests before delivery. Fully compatible with mainstream international standards, our camlock connectors are well‑suited for temporary power distribution for large concerts, theatre stages, exhibition events and film shooting sites. For stage rental firms and event engineering contractors, dependable camlock connectors guarantee stable power supply, improve on‑site wiring efficiency and reduce unexpected electrical hazards during live events.
